The Pratic Rialto is the elegant design version of the Pratic Nomo/Rialto family of aluminium pergolas: the same maximum dimensions of 550 × 700 cm, the same 10 × 32 cm load-bearing profile and the same Serie Glass compatibility in four glass finishes, with 10 × 15 cm posts that reduce the structural presence and give the whole a slimmer, more refined character. The manufacturer positions it as “Italian style for the exterior of pure elegance” — the Rialto is the choice when design and structural discretion are the priority, and the project does not require the additional robustness or the Raso awning of the Nomo.
The combination of slender 10 × 15 cm posts with a 10 × 32 cm load-bearing profile is the Rialto’s structural signature: a fine upright section that contrasts with the depth of the horizontal profile, creating a shadow line and a distinctive visual presence that elevates the pergola’s design above conventional solutions. The result is a refined-looking structure that integrates naturally into terraces with contemporary architecture and high-end garden projects.
The Rialto is compatible with the Serie Glass perimeter glazing system in four glass finishes: transparent Clear Glass, satin Satin Glass, smoked Smoked Glass and mirrored Mirrored Glass. This complete selection allows the level of privacy and transparency of the enclosure to be adapted to the specific context of each project, from maximum visual openness to a mirror-effect enclosure. Combined with the Living Series Mod-Lines modular furniture, the Rialto creates a fully equipped outdoor space.
Available as a freestanding version with four posts or wall-mounted, with coupleable modules to cover larger widths. Compatible with the modular Set platform for installations on uneven ground, and with Living Series Drapes and Ray profiles to complete the space design.
| Cover type | Motorised retractable PVC canvas |
|---|---|
| Installation | Freestanding (4 posts) / Wall-mounted |
| Minimum width | 250 cm |
| Maximum width | 550 cm |
| Minimum projection | 150 cm |
| Maximum projection | 700 cm |
| Maximum height | 270 cm |
| Posts | 10 × 15 cm |
| Load-bearing profile | 10 × 32 cm |
| Operation | Motorised |
| Drainage | Tilting gutter + integrated drainage in posts |
| Serie Glass | Yes — Clear / Satin / Smoked / Mirrored |
| Raso | No |
| Set compatible | Yes |
| Powder coating | Qualicoat Seaside Class 2 |
| Manufacture | Pratic — Italy · Made to measure |
| Official distributor BCN/MAD | Cortinsa |
Serie Glass (perimeter glazing — Clear, Satin, Smoked, Mirrored), Living Series Mod-Lines and Drapes (furniture and ornamental curtains), Ray (decorative profiles), Set (modular platform), LED Line (white or RGB), Double roof (interior finish in three tones), Google Assistant and Amazon Alexa home automation, light / rain / wind sensors.
RAL 9016 White sablé · RAL 1013 Avorio sablé · RAL 9006 Grey sablé · RAL 9010 White semi-gloss · RAL 1013 Avorio semi-gloss · RAL 9006 Matt bright aluminium · Grigio ferro · Corten · Tiger Coating · Custom RAL (Class 2).
The Pratic Rialto aluminium pergola is the solution from the Pratic range for high-end terraces and gardens where refined design and compatibility with quality perimeter glazing are the primary requirements. With 10 × 15 cm pillars, a 10 × 32 cm load-bearing profile and the Serie Glass available in four glass finishes — Clear, Satin, Smoked and Mirrored — the Rialto is the most elegant alternative to the Pratic Nomo for residential projects where the additional robustness and the Nomo’s Raso are not required. At Cortinsa we install the Pratic Rialto in Barcelona and Madrid with a technical site visit, made-to-measure fabrication and installation by our own team.
The Pratic Rialto and the Pratic Nomo share a 10 × 32 cm load-bearing profile, maximum dimensions of 550 × 700 cm and the Serie Glass in four finishes. There are three differences: the Rialto has 10 × 15 cm pillars compared to the Nomo’s 15 × 15 cm (more elegant vs more robust), a maximum height of 270 cm compared to the Nomo’s 300 cm, and it does not accept the Raso awning that the Nomo integrates into the profile. For attached residential terraces where structural elegance and glass enclosure are the priority, the Rialto is the right choice. For HORECA projects requiring a free-standing structure 300 cm in height with a Raso, the Nomo is the alternative.
The Pratic Rialto with Serie Glass is particularly well suited to detached residential and luxury apartment terraces in Barcelona and Madrid where a made-to-measure aluminium pergola with an integrated glass enclosure of a high aesthetic standard is sought. The four available glass finishes — from fully transparent to mirrored — allow the outdoor space to be configured with the degree of privacy and visual openness best suited to each orientation and setting. For projects requiring technical documentation, our BIM Library contains the Revit (.rfa) and IFC files for the Pratic range. Cortinsa installs the Pratic Rialto in Barcelona, Madrid and the surrounding metropolitan area with over 20 years of experience in pergolas and technical solar protection.
Yes. With the canvas extended, the tilting channel system and integrated drainage in the pillars channels rainwater to the outside. For lateral protection against rain with wind, combining it with the Glass Series is recommended.
